AKG K240 Repair for a Friend

Here’s another AKG K240 repair job.  I took on the job of repairing my friend’s headphones after they had already been repaired once.  Since I had a good experience with repairing mine I thought I’d give it a try.  Here’s how it went:

IMG_1316

After removing the “emblem” cover:

IMG_1317

Take out the two screws

IMG_1319

Ready to open:

IMG_1321

Apparently, the previous fix used some sort of putty or chewing gum to hold it all together.  Unfortunately, the bars and wires could still move around and one of the previously repaired solder joints had failed again.  So I took out all the gum and got the epoxy ready.

IMG_1323

After getting some of the gum out:

IMG_1325

Had this epoxy in the shop for some time, had to see if it was still good…it was.

IMG_1329

All cleaned up, new solder joints on both bars and ready for epoxy.

IMG_1334

The epoxy cures so quickly, I had to make a third batch for the actual repair.

IMG_1339

After putting on the epoxy:

IMG_1342

After burying the screw, I thought that might not be so good if there were ever another attempt to remove the bars again, so while the epoxy was still gummy, I removed the screw, cleaned up the area and removed the epoxy from the screw.

IMG_1345

After cleaning the screw off, I gave it a light coat of petroleum jelly and put it back in.

IMG_1350

Here’s one last look inside before re-assembly:

IMG_1352

Time for some final re-assembly after 20 minutes or so…

IMG_1360

And back in the box for an hour to cure.

IMG_1365

After one final test, call it done…good as new!

AKG 240 Studio Headphone Repair

Last night I discovered the left side of my AKG 240 Studio headphones was flakey. With a bit of searching, I found this was a pretty common failure for this model. After reading and looking at a few tutorials on the web, I decided to go for the repair. The failure point was obvious once I got them open, a flakey connection that became fully open once I exposed it. Follow along as I document my 15 minute journey to repair them.

IMG_5880
Just getting started, need to peel back the gold cover “emblem” by prying off with my fingernail.
IMG_5883
Once that was off, the two Phillips head screws were exposed.
IMG_5886
Once the screws were out, I gently pulled off the cover exposing the wires and the red one just popped off completely. I also found a small bit of plastic broken off from the piece over the cross-bars.
IMG_5890
After peeling back the insulation on the wire and tinning it, I soldered it back in place with a generous blob of solder.
IMG_5899
If you notice, I touched the plastic around the edge a bit with the soldering iron, but it’s no problem, they went back together nicely.
IMG_5901
The cause appears to be because of the movement of the two cross-bars that not only provide the mechanical connection from left to right, but also carry the audio signal electrically. If this should happen again, I will probably get out the J-B Weld and epoxy over where the cross-bars connect so they don’t move around so much in there. But for now, all is working once again. Yeah!
